Types of scheduling processes:

Long-term scheduling

once a new process is accepted (and partially created) it may enter the scheduling queues in one of two places:

—If all resources (such as memory requirements) are initially
fully available to the new process, it may be admitted to the tail
 of the Ready queue.

—If not all resources are immediately available, the new process
may be instantiated in the Blocked-Suspended queue until those
resources are provided.

Medium-term scheduling

• determines when processes are to be suspended and resumed
• The medium-term scheduler runs more frequently,
• deciding which process’s pages to swap to and from the
•  swapping device: typically once a second.

Short-term scheduling

—determines which of the ready processes can have
CPU resources, and for how long.

—also called as the dispatcher

executes most frequently(every few hundredths of a second) making
fine-grained decisions

as to which process to move to Running next.

—is invoked whenever an event occurs

—provides the opportunity, or requires, the interruption of the

 current process and

the new (or continued) execution of another process.


BY:
NOR AQILAH BINTI KAMARUZAMAN
NURHAYATUN NISHA BT SAHARUDIN
SHAIDATUL HIDAYU BT MOHAMMAD SABRI

3.2.3 Explain the following scheduling algorithms

a)First In First Out(FIFO)

The simplest scheduling discipline

—Processes are dispatched according to their arrival time on the ready queue

—Process that has the CPU will run until complete

—Non preemptive scheduling algo.

b. Round-Robin Scheduling

• processes are given equal time slices called quanta (or quantums)
• takes turns of one quantum each
• if a process finishes early, before its quantum expires,
• the next process starts immediately and gets a full quantum
• in some implementations, the next process may get only the rest of the quantum
• assume a new process arrives and goes into the
• queue before the process is removed from the processor

c. shortest job first

• another name is Shortest Process Next algorithm
• a better name may be shortest next-CPU-burst first
• assumes we know the length of the next CPU burst of all ready processes
• the length of a cpu burst is the length of time a process would
• continue executing if given the processor and not preempted
• SJF estimates the length of the next burst based on the
•  lengths of recent cpu bursts
• starts with a default expected burst length for a new process
• suppose that time intervals are numbered 1 for first cpu burst, 2 for second cpu burst, etc.
• default length is e(1), the expected length of time for the first cpu burst
• unlike other scheduling algorithms, this algorithm assumes that information about a process's burst length is stored between the times when it is ready.
• in keeping with the need for efficiency, only a small amount of info is stored and only a simple calculation is performed
• we can weight the previous expectation (representing all previous bursts) and the most recent burst with any two weights that add up to 1, e.g., say 0.5 and 0.5, or 0.9 for previous expectations and 0.1 for actual time for most recent cpu burst

d. shortest remaining time

·         very short processes get very good service

·     a process may mislead the scheduler if it previously ran quickly but now may be cpu intensive (this algorithm fails very badly for such a case)

·         the penalty ratios are small;

·         this algorithm works extremely well in most cases

this algorithm provably gives the highest throughput (number of processes completed) of all scheduling algorithms if the estimates are exactly correct.

e. priority

·         processor is allocated to the ready process with the highest

priority (we will assume that the highest priority is 0, as in UNIX and LINUX)

·         if all arrive at time 0 and are to run to completion, the C, D have

the highest priority, etc.

·         if there is a tie, choose the processes in alphabetical order
·         impractical and unrealistic in practice

f. multilevel queue

·         priorities are implicit in the position of the queue that the ready process

 is currently waiting in

·         when process is running on the processor, the OS

must remember which queue it came from

·         after a process has executed for one time quantum,

it is moved down one queue

·         process is placed at the back of the queue
·         a ready process is initially (implicitly) given a
high priority, then, as it uses time while still remaining ready,

·         this is close to what is used for the traditional UNIX scheduler

 its priority is lowered

By:
NUR FARRAHANA BT MOHD ROSLAN
NUR HIDAYAH BT AZIRID

ZATTY ILYANI BT ABDULLAH

warga-warga utilities~

Warga2 GROUP B "UTILITIES"

SHAIDATUL HIDAYU BT MOHAMMAD SABRI 10QIP11F1051

NUR FARRAHANA BINTI MOHAMAD ROSLAN 10QIP11F1056

NOR AQILAH BINTI KAMARUZAMAN 10QIP11F1042

NURHAYATUN NISHA BT SAHARUDIN 10QIP11F1067

NUR HIDAYAH BINTI AZIRID 10QIP11F1053

ZATTY ILYANI BT ABDULLAH 10QIP11F1066

USER INTERFACE

lA user interface is the system by which

people (users) interact with a machine.

 The user interface includes hardware

(physical) and software (logical) components.

lUser interfaces exist for various systems,

and provide a means of:

-Input, allowing the users to

manipulate a system, and/or

-Output, allowing the system to indicate

 the effects of the users' manipulation.

lUsers may also interact with the

operating system with some kind of

software user interface like typing

commands by using command line interface

(CLI) or using a graphical user interface.

lFor hand-held and desktop computers,

the user interface is generally considered

part of the operating system.

lOn large multi-user systems such as

Unix-like systems, the user interface is

 generally implemented as an application

program

that runs outside the operating system.



Operating System Placement

      The user interface has two main components:

lPresentation language, which

 is the computer-to-human part of the

transaction.

lAction language that characterizes

the human-to-computer portion

Types of User Interfaces

  There are several types

      of user interfaces:

lCommand Line Interfaces.

lMenu interfaces.

lGraphical User Interfaces (GUIs).

lVoice User Interfaces.

lWeb Form Interfaces.

Command interfaces

lUser types commands to give

instructions to the system e.g. UNIX

lMay be implemented using

 cheap terminals.

lEasy to process using

compiler techniques.

lCommands of arbitrary

complexity can be created by

command combination.

lConcise interfaces requiring

 minimal typing can be created.

Menu Interfaces

lMenu Interface presents user

with a menu of choices.

lRather than learning specific

commands, user choose them

from the menu.

lMenus can contain submenus,

in which case user need to

memorize how to access a

particular command.

lThis is still much easier than

memorizing the actual command.

Graphical User Interface (GUI)

lA graphical user interface or GUI (sometimes
pronouncedgooey) is a type of user interface item that allows
people to interact with programs in more ways than typing such
as computers
lExamples: hand-held devices such as MP3 Players, Portable
Media Players or Gaming devices; household appliances and
office equipment with images rather than text commands.
lA GUI offers graphical icons, and visual indicators, as
opposed to text-based interfaces, typed command labels or text
navigation to fully represent the information and actions available
to a user.

VoiceUser Interface

lA Voice User Interface (VUI) makes human interaction with computers possible through a voice/speech platform in order to initiate an automated service or process.

lThe VUI is the interface to any speech application.

lControlling a machine by simply talking to it was science fiction only a short time ago.

lHowever, with advances in technology, VUI have become more common place, and people are taking advantage of the value that these hands-free, eyes-free interfaces provide in many situations.

Web Form Interfaces

lWeb Form interfaces are onscreen forms displaying fields containing data items or parameters that need to be communicated to the user.

lWeb Form interfaces may be implemented using the Web

lA Web Form allows a user to enter data that is sent to a server for processing.

lWeb forms resemble paper forms because internet users fill out the forms using checkboxes, radio buttons, or text fields.

lFor example, Web Forms can be used to enter shipping or credit card data to order a product or can be used to retrieve data (e.g: searching on a search engine).

lIn addition to functioning as input templates for new information, Web Forms can also be used to query and display existing data in a similar manner to mail merge forms, with the same advantages..

1.


WebForm Interfaces

lWeb Form interfaces are onscreen forms displaying fields containing data items or parameters that need to be communicated to the user.

lWeb Form interfaces may be implemented using the Web

lA Web Form allows a user to enter data that is sent to a server for processing.

lWeb forms resemble paper forms because internet users fill out the forms using checkboxes, radio buttons, or text fields.

lFor example, Web Forms can be used to enter shipping or credit card data to order a product or can be used to retrieve data (e.g: searching on a search engine).

lIn addition to functioning as input templates for new information, Web Forms can also be used to query and display existing data in a similar manner to mail merge forms, with the same advantages..

Distributed Operating System

—A Distributed Operating System is the one that runs on multiple, autonomous CPUs which provides its users an illusion of an ordinary Centralized Operating System that runs on a Virtual Uniprocessor.

—Distributed Operating Systems provide resource transparency to the user processes.

  “If you can tell which computer you are using, you are not using a distributed operating system.” - Tanenbaum

—The Distributed Operating System is unique and resides on different machines.

— User processes can run on any of the CPUs as allocated by the Distributed Operating System.

— Data can be resident on any machine that is the part of the Distributed System.

— All multi-machine systems are not Distributed Systems.

“It is the software not the hardware that determines whether a system is distributed or not” - Tanenbaum

—Advantages:

-Price/Performance advantage (Availability of cheap and powerful Microprocessors).

-Resources Sharing

-Computation speed up – load sharing

-Reliability and Availability.

-Provides Transparency.

—Disadvantages:

1)Lack of security - Easy access also applies to secret data.

—An example of a distributed system: Amoeba

-An open source microkernel-based distributed operating system developed by Andrew S. Tanenbaum and others at the Vrije Universiteit.

-The aim of the Amoeba project is to build a timesharing system that makes an entire network of computers appear to the user as a single machine.

-Development seems to have stalled: the files in the latest version (5.3) were last modified on 12 February 2001.

-Amoeba runs on several platforms, including i386, i486, 68030, Sun 3/50 and Sun 3/60.




WRITER-->Shaidatul Hidayu bt Mohammad Sabri (F1051)
